The Definium 120 Suite allows for an offset glazing system or double glazing partition system, incorporating 92mm stud and 13mm plasterboard. This robust aluminium suite offers a multitude of possibilities, and is specially designed and engineered to achieve your vision with three different glazing options: centre, offset and double glazed.
All three options are interchangeable, working in conjunction with selected Platinum sections. The Definium 120 Suite has been designed with precision for ultimate performance and installation efficiency, so whether you’re after a double glazing partition system or an offset glazing system, it can provide a flexible solution suitable for your needs.
12.5mm & 10.5mm VLam Hush Glass - Double Glazed - RW49
12.38mm & 10.38 Laminated Glass - Double Glazed - RW47
12.5mm VLam Hush Glass - Single & Offset Glazed - RW38
12.38mm Laminated Glass - Single & Offset Glazed - RW35
